High-Head Performance
Designed for demanding pumping applications requiring high pressure and head.
XYLEM
Godwin Heidra 150HH
High-head hydraulic submersible pump for demanding dewatering applications.
The Godwin Heidra 150HH is a hydraulically driven submersible pump designed for demanding high-head pumping and dewatering requirements.
OVERVIEW
High-head performance for demanding dewatering.
The Godwin Heidra 150HH is part of the Godwin High Head Heidra range. Its hydraulic submersible configuration and high-head capability make it suitable for demanding water transfer and dewatering applications.
Hydraulic Drive
Hydraulic drive supports submersible pump operation in demanding working conditions.
Solids Handling
Handles solids up to 35 mm for demanding dewatering applications.
Submersible Configuration
The pump can be positioned directly at the water source for dewatering and water transfer operations.
PRODUCT PROFILE
Technical data and primary uses.
The final configuration still needs to match your application conditions and on-site technical evaluation.
| Pump Size | 150 mm (6") |
|---|---|
| Solids Handling | 35 mm |
| Operating Speed | 1,600–2,200 rpm |
| Hydraulic Oil Flow | 20–133 |
| Hydraulic Pump Type | Variable piston |
| Hydraulic Pressure | 250 bar |
| Power Pack | GHPU50 |
APPLICATIONS
Designed for real operational requirements.
Mine Dewatering Pumps – Open Pit Underground
Supports water removal and management in open-pit and underground mining operations to help maintain workable site conditions.
Mining Source Water – Pumps & Treatment
Pumping solutions for managing source water used across mining processes and operational requirements.
Water Management and Pumps for On-Pad Water
Supports water transfer and management across mining process areas requiring flexible and reliable pumping systems.
Combined Sewage & Stormwater Handling
Helps transfer stormwater and contaminated water from operational areas to support effective site water management.
Storm Water Management Systems
Supports the control, transfer and management of stormwater across mining sites and supporting infrastructure.
PRODUCT REFERENCEInformation you can verify.
The details on this page are drawn from the principal's own catalogues and official references.
