Heavy-Duty Dewatering
Designed for heavy-duty dewatering in abrasive and demanding operating conditions.
XYLEM
Flygt 2400
Heavy-duty submersible dewatering pump for abrasive and demanding mining conditions.
The Flygt 2400 is a heavy-duty submersible dewatering pump for water containing clay, stone chips, drilling fines and heavy sediment.
OVERVIEW
Tough dewatering for demanding operating conditions.
The Flygt 2400 is engineered for demanding dewatering applications, including abrasive, corrosive or salt-water conditions. It is suited for pumping water containing clay, stone chips, drilling fines and heavy sediment from sumps, mine areas and flooded locations.
Heavy Sediment Handling
Handles water containing clay, stone chips, drilling fines and heavy sediment.
Cast-Iron Construction
Cast-iron construction supports durability in heavy-duty applications.
High-Chrome Impeller
High-chrome impeller provides increased wear resistance in abrasive conditions.
Deep Submersible Operation
Supports immersion depths up to 20 metres for mine dewatering applications.
Explosion-Proof Design
Designed as an explosion-proof dewatering pump for selected heavy-duty applications.
PRODUCT PROFILE
Technical data and primary uses.
The final configuration still needs to match your application conditions and on-site technical evaluation.
| Rated Power | 104 kW |
|---|---|
| Discharge Connection | 4" / 6" |
| Max. Immersion Depth | 20 m |
| Max. Liquid Temperature | 40°C |
| Weight | 900–985 kg |
APPLICATIONS
Designed for real operational requirements.
Open-Pit & Underground Mine Dewatering
Supports water removal from pits, sumps and underground working areas to help maintain mine operations.
Mining Source Water – Pumps & Treatment
Supports the transfer and management of source water for mining processes and operational requirements.
Face & Stage Dewatering
Supports dewatering at tunnel faces and working stages to help maintain controlled working conditions.
Heavy Sediment & Abrasive Water Handling
Handles water containing clay, stone chips, drilling fines and heavy sediment in demanding mining conditions.
Flooded Mine Area Dewatering
Supports drainage of flooded working areas to help restore mine access and operational activities.
PRODUCT REFERENCEInformation you can verify.
The details on this page are drawn from the principal's own catalogues and official references.
